HUBSAN ACE SE Standard version Details review

Buy HUBSAN ACE SE Standard version /Battery/Instruction manual/Spare Parts Link：

★ HUBSAN ACE SE Standard version Drone Body

★ HUBSAN ACE SE Standard version Battery

★ HUBSAN ACE SE Standard version Manual book

★ HUBSAN ACE SE Standard version Spare parts

HUBSAN ACE SE Brand New series

Brand New DronesState of the Art Technology
New HUBSAN ACE Series Launch
Brand New Drones, State of the Art TechnologyUltra-Clear 4K Video, Aerial Photography Adventure Affordable Drone, Display Fantastic Fly arts

4K Video

ACE SE uses a 1/2.6 inch CMOS image sensor, which can shoot

4K 30-frame high-definition video, fully retaining every creativedetail, and sense of reality.

1080P syncleas 3 digital imagetransmission system

SyncLeas3.0 upgrades the adaptive spectrum sensingfunction, the intelligent frequency modulationalgorithm effectively avoids interference frequencypoints, and the channel coding algorithm adopts theLDPC code used in deep space communication, whichhas super error correction capabilities. It further ensurethe reliability of image transmission. The aircraft imagetransmission bandwidth can reach up to 20Mbps, andthe image quality and details of the image transmissionare increased by 400%. Whether in the city or in thewilderness, you can enjoy a stable and smooth dronecontrol experience.

10km HD image transmission

ACE SE comes SyncLeas3.0 image transmission system,the distance is up to 10km which broadens our horizonsand will help us roam in wild.

3 axis stable gimbal

Stable aerial images are digital currency for many.profit from the HUBSAN new Technology three-axis highperformance gimbals. Enrich your aerial photography,even high-speed flight can also record silky smoothvideos.

Powerful, maximum level 8 wind resistance

The fastest flight speed ofthe ACE SE can reach 16m/s,profiting from the third-generation self-developedflight controlalgorithm and excellentelectromechanicalpower efficiency. In the sport mode, ACE SE offerslevel 7 wind resistance, and in wind resistance mode,ACE SE offers level 8 wind resistance so you can flyworry free in high winds.

HUBSAN Third generation(ATVT3.0)Visual Tracking

The ACE SE visual tracking mode adopts the third-generation intelligenttracking algorithm (ATVT 3.0). The visual tracking ability has beensignificantly improved on the basis of ATVT 2.0. The upgraded versionofthe neural network acceleration engine cooperates with the upgradedversion of the Alpattern matching and detection algorithm. Greatlyimproves the tracking accuracy and significantly reduce the trackingdelay. In the tracking mode, the drone can automatically match andframe common objects such as people, bicycles, and cars, which greatlyfacilitates the control experience in the tracking mode.

Intelligent Battery

ACE SE battery uses 3s lithium polymer battery,all batteries are equipped with intelligent batteryprotection and management unit, which implementssafety while achieving high-precision estimation andstatistics on battery power, safety protection circuitthen combined with a thorough power protectionstrategy and power on/off control algorithm, togreatly enhance safety ofthe drone and battery.

Maximum flight time of 35 minutes

ACE SE offer35 minutes offlightendurance in a windless environment

Upgraded HUBSAN third-generation FC,more stable hover and a much smoother flight

HUBSAN ACE SE creatively adopts constanttemperature and altitude sensor technology toenhance the reliability of altitude data, whileusing Tof and barometer to fix the height, visionand GPS to fix the point, and combining with thethird generation of flight control digital fusiontechnology, which obviously enhances the hoveringstability of the aircraft.

19 smart modes, easy to get started,can take off and land with one key,quick and easy movie-making

Active Tracking mode

The drone can automatically match and frame common objects suchas people, bicycles, and cars, which greatly facilitates shooting inactive tracking mode.

Zoom

Support 3x digital zoom, to capture every detail during the flight.

Live streaming

ACE SE support online live streaming: Breaking through the traditional space limitations, in X-HUBSAN2.0live streaming in the air and share a more magnificent picture, showinga completely different perspective.

MULTI-SMART MODE
Support manualadjustment of parameters,giving creators morecreative space

Light and Portable

Foldable,weight 543g, excellent portability,best partner for travel and outdoor sports

---

Overview

AlRCRAFT	HUBSAN ACE SE
Size	Expand:182*176.5*73mm Folding:118.7*172.5*73mm
Diagonal wheelbase	246mm
Maximum current	34A
Take off weight	543g
Hover accuracy	Indoor: vertical±0.1m,horizontal±0.1m   Outdoor: height<7m, vertical<Height*0.02m Horizontal<Height*0.02m Height>7m Vertical±0.1m Horizontal±0.5m
Maximum ascending velocity	3m/s(N)  4m/s(S)  1m/s(F)
Maximum descending velocity	1.5m/s(N)  3m/s(S)  1m/s(F)
Maximum horizontal flight speed	Normal mode:8m/s(N,No wind at sea level) Sports mode:16m/s(S, No wind at sea level) Movie mode:lm/s(S, No wind at sea level)
Maximum take-off altitude	5000 meters
Maximum anti-wind capability	Grade 8 wind(16m/s)
Maximum tilt angle	30° (S) 20° (N)  20° (F)
Global Position	GPS/GLONASS,BeiDou
Flight duration	Hovering for 33 minutes (Windless,measured in 2~4 meters hovering)   Slow flight time 35 minutes (8m/s uniform flight)
Color	White



POWER SYSTEM
Propeller	Folding propeller diameter 143mm
ESC	Digital ESC: Brushless 20A x4



BATTERY
Category	Li-ion battery 3S
Capacity	3800mAh
Nominal voltage	11.4V
Charging voltage limitation	13.05V
Discharge limitation	8C
Charging time	90 minutes
Battery weight	233g
Working temperature	-5℃～40℃
Charging environment temperature	0℃～40℃
Smart battery balance	Support
Smart battery	Support
Smart Charging head	Support
Battery Smart buckle	Support
Automatic discharge	Support
Hibernation Mode	Support



CAMERA
Video	4K:3840×2160@30fps 2.7K:2720×1530@30fps FHD:1920×1080@30fps
Sensor	1/2.6 inch CMOS sensor
Shutter speed	1/25s-1/8000s
Hlog	Support
Portrait Mode	Support
Focus point	0.5m to infinity
Video compression method	H.264
Lens specifications	FOV 80° EFL3.5mm Aperture f/2.2 Focus point 0.5m to infinity Distortion<1.5%
Video bitrate	64Mbps-100Mpbs
Photo format	JPEG
Video format	MP4
control method	App, remote control
Firmware upgrade	OTA
USB interface	Micro-USB
Support memory card type	microSD,U3 or Class10 16G/32G/64G/128G



COMMUNICATION
Wireless transmission solution	SyncLeas 3
Transmission delay	Within 200ms
wireless transmission distance	FCC:10km; CE:<= 6km; SRRC:<=10km
Antenna position	forearm support foot
band mode	frequency button
Default remote	HT018F



REMOTE CONTROLLER
Wireless transmission solution	SyncLeas 3
Highlight LED display	Support
Working temperature	-5°-50°
Effective range	FCC:10km; CE:6km;SRRC:10km
Built-in battery	4400mAh
Buzzer	Support
Supportable mobile system	Android,iOS
Continuous working time	2.5h(Normal flight time)
Supportable interface type	Lighting, MicroUSB, USB-typeC



FLIGHT CONTROLLER
Flight controller version	Third-generation flight controller
Basic flight mode	wind resistance mode/Sports mode/ Normal mode/Movie mode
Altitude hold	Tof, barometer
Fixed-point function	Vision optical flow,GPS
Unlock/lock	Outer-eight unlock/lock
Fill light	Support 0.5m-5m low light environment to automatically turn on the light
Out of control protection	Support
Home recognition (Search the drone apron)	Support
Vision tracking	Third-generation tracking technology (ATVT 3.0)
Auto drifting	Support
Waypoint flight	Support
Flying around	Support
Time-lapse photography	Support
Intelligent battery	Power Management, Overcurrent Protection, Over-discharge Protection, Overcharge Protection,Balanced Charging, Auto-Discharging Protection
Low battery protection	automatically return to home and land on low battery
ESC	self-developed ESC,digital PWM
Motor stall protection	Support



APP
APP	X-Hubsan2
Mobile device	IOS 10.0 or higher Android 6.0 or higher



The Hubsan Ace SE is a powerful drone that provides all the features you need to take your hobby to the next level. With a max speed of 16 m/s, max range of 10 km and max flight time of 35 minutes, this drone is perfect for long-distance flights. The 3800 mAh battery capacity means you can fly your drone for longer periods of time without having to stop and recharge. The Orbit Mode allows you to circle an object while shooting video from different angles, the Follow Mode lets you follow an object while filming it, and the Waypoint Mode helps you plan out how your drone will fly with pre-programmed settings. If you're looking for a drone that has it all, then look no further than the Hubsan Ace SE.

The Hubsan Ace SE is a Multirotors drone that was released by Hubsan in 2021.

A multirotor drone is a multiple propeller, vertical lift drone. These drones are more maneuverable due to their flight profile, being able to fly much closer to buildings and other obstacles. Multi-rotor drones like the Hubsan Ace SE also tend to be faster to deploy, and tend to be significantly cheaper to acquire and operate.

The Hubsan Ace SE sits on the slower side of drones, with a max speed sitting around 16 m//s. This might not be a bad thing though, so it really depends on why you're looking at buying the drone. If you're happy with a slightly slower drone then this one could be what you're after.

With a well above the average maximum range of 10 km, you're guaranteed a long-distance flight. Be assured you'll reach the distance you need, from the comfort of your mobile office, or even your couch, and know that your drone won't just disappear off into the distance.

The drone sits well within an average flight time when compared to other drones, with a maximum flight time of 35 min. This flight time will be plenty of the average user, and should give you more than enough time between charges. You can always bring an extra battery to swap out between flights, or just a battery pack to charge it up as you go should you need a little more flight time.

---

Other precautions

---

FLIGHT ENVIRONMENT REQUIREMENTS
(1) Select an open area to fly. Avoid high rise buildings and tall obstacles (such as
trees and poles). Near buildings and obstacles, flight control signals and GPS
signals are severely affected; GPS functions such as GPS mode and Return to
Home may not function properly.
(2) Do not fly in bad weather conditions (such as in wind, rain or fog).
(3) Fly the aircraft in ambient temperatures of 0-40 ℃.
(4) When flying, please stay away from obstacles, people and crowds, high voltage
lines, trees, water, etc.
(5) To avoid remote control signal interference, do not fly in strong electromagnetic environment (such as venues with radio stations, power plants and Phone
antenna and TV towers).
(6) The aircraft cannot be used at or near the Arctic circle or Antarctica.
(7) Do not fly in no-fly zones.
(8) Do not operate the aircraft near high pressure lines, airports or areas with
severe magnetic interference.

---

HUBSAN ACE SE Standard version Safety Notice for Intelligent battery
● If you do not plan to use the product for a long period of time, make sure to
discharge the battery voltage to above 11.7V. If the voltage is higher than
11.7V, the battery voltage will automatically start to discharge to 11.7V after
two days without pressing the battery button. Maintaining and storing the
battery voltage with 11.7V can increase battery life.
● Please use only HUBSAN chargers or HUBSAN Charging Hub for
battery charging.
● Discharge the battery at 5C current or below. To avoid discharge related
battery damage, do not discharge for longer period of time than advised.
● Do not charge in a flammable and explosive environment to prevent fire.
● Batteries need to be recharged if unused for over 3 months.
1. Do not disassemble or reassemble the battery.
2. Do not short-circuit the battery.
3. Do not use or charge near sources of heat.
4. Do not put the battery in contact with water or any kind of liquid.
5. Do not charge batteries under sunlight or near fire.
6. Do not puncture or subject the battery to force of any kind.
7. Do not discard unused batteries to regular trash.
8. Never charge a battery that has been damaged, become deformed
or swollen.
9. Do not solder on or near the battery.
10. Do not reverse charge or over discharge the battery.
11. Do not reverse charge or reverse the battery polarities.
12. Do not connect the battery to a car charger / cigarette lighter or any kind
of unconventional power source.
13. This battery is prohibited to use with non-designated devices.
14. Do not mix other types of batteries with lithium batteries.
15. Do not exceed the specified charging time.
16. Do not place the battery in a microwave or in areas of high pressure.
17. Do not expose the battery to the sun or excessive heat.
18. Do not fly in places with strong interference（ high-voltage line, power
stations, base stations, high-speed rail lines, signal towers, etc.）.
19. Do not use or charge in temperatures below 0 ℃ and above 45 ℃.
20.Warning: Prohibited charging the battery without turning off the battery
on the aircraft first ！
21. If a newly purchased battery showing, leaks, possesses a bad smell or other
abnormalities, contact and return the battery immediately to the vendor.
22. Keep away from the reach of children.
23. Use a dedicated battery charger only and follow all charging guidelines.
24. Adults must supervise minors, if allowed to charge the batteries even
when using dedicated HUBSAN chargers.
